Product Features：
1). Ultra-small size, light weight, streamline, fully sealed and easy to carry;
2). Competitive price design, high reliability, ultrasonic lamination;
3). Built-in over voltage, over current and short circuit protection;
4). Input Characteristics: Voltage :100-240VAC ± 10%; Frequency: 50/60Hz; Current: 1.6A Max;Starting Time: 3s Max; Inrush Current: 60A/240VAC Max;
5). Output characteristics: constant voltage mode, high precision, low noise;Hold up time: 20mS Min;
6). Environmental: Operating temperature: 0 ℃ -40 ℃, 5% -90% RH;Storage temperature: -20 ℃ -85 ℃, 5% -95% RH;
7). Cooling mode: natural cooling;
8). Energy efficiency accordingly: ERP / CEC-V standard;
9). Safety standards: IEC/EN/UL60950;
10).Meet ROHS standards;
11).Input Block type：IEC-C6/IEC-8/IEC-14；
12).Average failure rate: 50,000 hours;
13).Electrical characteristics: (see below sheet)

Model	I/P Condition	Output（V）	Output（A）	Output（W）max
SK08G-XXXXYYY		5.0-8.9V	0.1-7.8A	60W
SK08G-XXXXYYY	100-	9.0-11.9V	0.1-7.0A	68W
SK08G-XXXXYYY	240VAC	12.0-18.9V	0.1-6.25A	75W
SK08G-XXXXYYY	1.5A Max	19.0-24.9V	0.1-3.95A	75W
SK08G-XXXXYYY	50/60Hz	25.0-36.9V	0.1-3.0A	75W
SK08G-XXXXYYY		37.0-48.0V	0.1-2.03A	75W
